DIY Table System (54"x30") - 3/4" System

SKU: FA75-PDY5430-FE-DS

Kit: Plate Only
Price:
Sale price$840.00 USD

The Maverick table series is a minimalist table designed for professional use.

  • Flat 1/2" thick steel plates. Our plates are ground for flatness, it's not a random piece of steel plate from the mill.
  • CNC machined holes.
  • Dragon Scale finish to protect against corrosion and weld spatter.
  • Ability to fine tune the plate in relation to the frame using set screws.
  • Table holes are 3/4" diameter on a 2" grid, designed for use with the Fireball 3/4" system clamps and fixtures.

Assembly Required

This table requires assembly by the customer. When you purchase the table kit, the plate, mounting hardware, tubular frame, and legs are all included.

Full assembly will require welding and/or drilling:

  • The table top does not need to be welded to the frame. For best flatness we suggest just bolting to the frame using the included steel straps
  • Tube frame does not need to be welded together, welding is optional
  • The legs require welding to attach the foot plate and nuts for the leveling feet
  • Attaching the legs to the frame requires welding or drilling/bolting
  • Attaching leg braces to the legs requires welding or drilling/bolting

Need a Larger Table?

This table can be quickly expanded by supplying new pieces of tubing to create a larger frame.

About the Fireball 3/4 System

The Fireball 3/4 table system features 3/4" diameter holes on a 2" grid and our innovative line of fixtures that are the fastest and easiest to use in our industry.

Furthermore, all fixtures in the 3/4 Fireball line are compatible with both 1/2" thick and 1" thick tables.

What Comes In The Kit 100?

Qty: 2

Qty: 2

Qty: 2

Qty: 2

Qty: 4

Qty: 4

Qty: 2

Avoid Arc Strikes with 3 Steps:

  1. Always ground directly to the workpiece.
  2. Clamp the workpiece down.
  3. Ensure you have a clean table surface
    Workpieces often make poor contact with the table, which increase the likelihood of arc strikes. Grounding directly to the work piece prevents this.
    Clamping the work piece down helps to maintain better contact between the work piece and the table.
    Having a clean table surface also ensures you have better contact between the table and the workpiece.

Why These Steps:

  • Workpieces often make poor contact with the table, which increase the likelihood of arc strikes. Grounding directly to the work piece prevents this.
  • Clamping the work piece down helps to maintain better contact between the work piece and the table.
  • Having a clean table surface also ensures you have better contact between the table and the workpiece.
